Our Advantages:
18kw air source heat pump - High-efficiency integration of cooling, heating and hot water, opening a new experience of low-carbon life
With energy savings of up to 60% and European environmental standard certification, it provides a year-round comfortable solution for homes and commercial spacesAir source heat pump system. Environmental protection innovation, leading the industry
R290 natural refrigerant: using propane (R290) environmentally friendly refrigerant, the global warming potential (GWP) is only 3, which is much lower than that of traditional refrigerants, in line with EU F-Gas regulations and global environmental protection trends, and contributes to the goal of carbon neutrality.
Let the R290 triple heat pump inject efficient and environmentally friendly smart energy into your space
| Model: | CHP-12Ⅲ/CD4 | CHP-18Ⅲ/CD4 | CHP-24Ⅲ/CD4 | |||||||||||||||||||||||||||||||||||||||||
| Power Supply | 380-415V 3N-/50Hz | |||||||||||||||||||||||||||||||||||||||||||
| Nominal Heating A7/W35 | Heating Capacity | kW | 12.00 | 18.00 | 24.00 | |||||||||||||||||||||||||||||||||||||||
| Power Input | kW | 2.67 | 3.91 | 5.58 | ||||||||||||||||||||||||||||||||||||||||
| Current Input | A | 4.90 | 7.30 | 10.30 | ||||||||||||||||||||||||||||||||||||||||
| COP | W/W | 4.50 | 4.60 | 4.30 | ||||||||||||||||||||||||||||||||||||||||
| Nominal Heating A7/W55 | Heating Capacity | kW | 12.00 | 17.10 | 22.80 | |||||||||||||||||||||||||||||||||||||||
| Power Input | kW | 4.12 | 6.43 | 8.60 | ||||||||||||||||||||||||||||||||||||||||
| Current Input | A | 7.60 | 11.90 | 15.90 | ||||||||||||||||||||||||||||||||||||||||
| COP | W/W | 2.91 | 2.66 | 2.65 | ||||||||||||||||||||||||||||||||||||||||
| Nominal Cooling A35/W7 | Cooling Capacity | kW | 10.30 | 15.30 | 17.50 | |||||||||||||||||||||||||||||||||||||||
| Input Power | kW | 3.75 | 5.86 | 6.73 | ||||||||||||||||||||||||||||||||||||||||
| Input Current | A | 6.90 | 10.90 | 12.50 | ||||||||||||||||||||||||||||||||||||||||
| SCOP(Water Temp. At 35°C) | / | A+++ | ||||||||||||||||||||||||||||||||||||||||||
| SCOP(Water Temp. At 55°C) | / | A++ | ||||||||||||||||||||||||||||||||||||||||||
| Retrigerant Type / Weight | / kg | R290/0.97 | R290/1.30 | R290/1.60 | ||||||||||||||||||||||||||||||||||||||||
| Fan Quantity | / | 1 | 2 | |||||||||||||||||||||||||||||||||||||||||
| Sound Pressure At 1m Distance | dB(A) | 52 | 54 | |||||||||||||||||||||||||||||||||||||||||
| Water Pressure Drop | kPa | 20 | 55 | |||||||||||||||||||||||||||||||||||||||||
| Water Piping Connections | inch | G1” | ||||||||||||||||||||||||||||||||||||||||||
| Operating Temperature Range (Heating Mode) | ℃ | -25~45 | ||||||||||||||||||||||||||||||||||||||||||
| Max. Outlet Water Temp | ℃ | 75 | ||||||||||||||||||||||||||||||||||||||||||
| Compressor Brand | / | HIGHLY | ||||||||||||||||||||||||||||||||||||||||||
| Circulating Pump | / | Built-In | ||||||||||||||||||||||||||||||||||||||||||
| Unpacked Dimensions(L×D×H) | mm | 1138×508×938 | 1138×508×1406 | |||||||||||||||||||||||||||||||||||||||||
| Packed Dimensions(L×D×H) | mm | 1168×538×958 | 1168×538×1426 | |||||||||||||||||||||||||||||||||||||||||
| Model Name: | CHP-10Ⅲ/CD3 | CHP-12Ⅲ/CD3 | CHP-14Ⅲ/CD3 | CHP-16Ⅲ/CD3 | ||||||||||||||||||||||||||||||||||||||||
| Power Supply: | V/ph/Hz | 380-420/3/50 | ||||||||||||||||||||||||||||||||||||||||||
| A7/W35 | Heating Capacity | KW | 10 | 12 | 14 | 16 | ||||||||||||||||||||||||||||||||||||||
| Heating Power Input | KW | 2.28 | 2.47 | 2.99 | 3.59 | |||||||||||||||||||||||||||||||||||||||
| COP | W/W | 4.39 | 4.86 | 4.69 | 4.46 | |||||||||||||||||||||||||||||||||||||||
| A7/W55 | Heating Capacity | KW | 10.99 | 11.99 | 14 | 16 | ||||||||||||||||||||||||||||||||||||||
| Heating Power Input | KW | 3.68 | 4.06 | 5.17 | 5.97 | |||||||||||||||||||||||||||||||||||||||
| COP | W/W | 2.99 | 2.95 | 2.71 | 2.68 | |||||||||||||||||||||||||||||||||||||||
| A35/W18 | Cooling Capacity | KW | 9.20 | 10.6 | 13.1 | 13.4 | ||||||||||||||||||||||||||||||||||||||
| Cooling Power Input | KW | 2.00 | 2.57 | 3.25 | 3.54 | |||||||||||||||||||||||||||||||||||||||
| EER | W/W | 4.60 | 4.13 | 4.03 | 3.78 | |||||||||||||||||||||||||||||||||||||||
| A35/W7 | Cooling Capacity | KW | 7.90 | 10.5 | 12 | 13.6 | ||||||||||||||||||||||||||||||||||||||
| Cooling Power Input | KW | 2.43 | 3.68 | 4.21 | 4.98 | |||||||||||||||||||||||||||||||||||||||
| EER | W/W | 3.25 | 2.85 | 2.85 | 2.73 | |||||||||||||||||||||||||||||||||||||||
| Max Input Cerrent | A | 26 | 13 | 15 | 16 | |||||||||||||||||||||||||||||||||||||||
| Max Input Power | KW | 5.3 | 6.5 | 7.4 | 8 | |||||||||||||||||||||||||||||||||||||||
| SCOP(Water Temp. At 35°C) | / | A+++ | A+++ | A+++ | A+++ | |||||||||||||||||||||||||||||||||||||||
| SCOP(Water Temp. At 55°C) | / | A++ | A++ | A++ | A++ | |||||||||||||||||||||||||||||||||||||||
| Fan Quantity | 1 | 2 | ||||||||||||||||||||||||||||||||||||||||||
| Sound Power Level (En12102 35℃ ) | dB(A) | 58 | 60 | 62 | 64 | |||||||||||||||||||||||||||||||||||||||
| Water Connection | Inlet Dia.(Mpt Gas | inch | 1.00 | 1.25 | 1.25 | 1.25 | ||||||||||||||||||||||||||||||||||||||
| Outlet Dia.(Mpt Gas) | inch | 1.00 | 1.25 | 1.25 | 1.25 | |||||||||||||||||||||||||||||||||||||||
| Unit Outdoor Dimensions (L*W*H) | mm | 1091*424*973 | 1091*424*973 | 1091*424*1363 | 1091*424*1363 | |||||||||||||||||||||||||||||||||||||||
Yes. Our PhD team has optimized the R290 cycle to ensure stable heating even in sub-zero Nordic extremes.
Absolutely. We offer full OEM/ODM services including logo silk-screening, custom colors, and localized UI software.
Our products are fully certified with CE, Keymark, and ErP A+++ for 2026 standards.
We promise that if the main parts of the product are damaged due to quality or process problems within 48 months, we will guarantee the product.
Customers can read our product catalog, browse different product introductions, or ask our customer service, our professional team will advise you according to your needs.
T/T, L/C at sight
45 days after the deposit received.
We accept all OEM orders, please contact us and send me your design. We will provide you with a reasonable price and provide you with samples as soon as possible.
We are R&D and manufacturer factory. We have 200,000 square meters of modern factories in Foshan and Liuzhou. OEM service is available.
